FTM102 Multifunctional xaiv-thiab-qhov chaw tshuab raug lees paub rau nws qhov kev ua tau zoo thiab versatility. Nws dual-taub hau, dual-workzone tsim, powered los ntawm kev ua haujlwm siab linear lub cev muaj zog ntawm x-axis, txhim kho ob qho kev nrawm thiab precision thaum lub sijhawm ua haujlwm dual-npab. Y-Axis nta lub siab-precision pob ntsia hlau ua ke nrog lub ntsej muag kev plhaw taub hau, xa cov kev ruaj khov ceev, thiab tus nqi-ua hauj lwm.
Nruab nrog kev lees paub lub zeem muag tshaj tawm, FTM102 captures thiab qhia txog cov khoom sib xyaw ntawm kev nrawm ntawm 2 M \/ S, uas pub rau kev kho lub sijhawm thaum lub sijhawm. Qhov no muaj peev xwm ua kom pom tseeb qhov chaw, ua rau FTM102 zoo tagnrho rau ntau yam ntawm cov haujlwm ua haujlwm nyuaj.
Kev tsis muaj
|
Kev Ua Tshwj Xeeb |
|
|
Txoj kev muab txoj cai |
Theem Lub Zeem Muag (Yws) + Flying Vision |
|
Nozzle thawv |
Yam ua tau |
|
Tus naj npawb ntawm spindles |
2 caj npab * 6 nozzles (tej zaum: 16 hli) |
|
Mounting ceev |
58000cph |
|
Mounting Qhov tseeb |
{0. 07 hli |
|
PCB Cheebtsam Ntau Yam |
0402 ~ 口 16mm, sop \/ qfp \/ csp thiab lwm yam (H15MM) |
|
Lub koob yees duab theem: 1300000 pixels, 30 * 28mm (yeem) |
|
|
PCB Loj |
Min: 50 (w) * 50 (l) hli |
|
Max: 320 (W) * 1200 (L) MM [YUG: 400 (W) * 1200 (L) MM] |
|
|
Tuab 0. 5 ~ 6 hli |
|
|
Feder Base |
8 hli * 32Feeder Noj * 2MMS |
|
Rated zog |
3.5kw |
|
Lub Zog \/ Cua Siab |
Ac {{{{0}} hz; 0. 5 ~ 0.7mpa |
|
Tshuab qhov hnyav |
1600kg |
|
Zuag qhia tag nrho |
1765 (L) * 1310 (w) * 1420 (h) hli (PCB ntws tawm yog nyob rau hauv liath) |
Cov lus piav qhia kom zoo dua
1200mm ntev pcb txhawb nqa: Pab txhawb kev sib tw ib leeg rau kev txhim kho kev ua tau zoo.
Dual-npab tso: Txhawb kev kub ceev, tib lub sijhawm tso.
Tus neeg siv-phooj ywg interface: Kev ua haujlwm zoo me me minimizes kawm kev kawm nkhaus thiab boosts tsim khoom.
Broad application page: ntau yam txaus kom haum rau ntau yam kev lag luam thiab kev xav tau ntau lawm.
Muaj qhov xwm txheej
Teeb Pom Kev Dob, Kev Siv Hluav Taws Xob, Khoom Siv Hauv Tsev, LED Thaj, 3C Accessories
